class: title-slide, inverse, center, middle # Model checking <div style="position: absolute; bottom: 15px; vertical-align: center; left: 10px"> <img src="images/02-foundation-vertical-white.png" height="200"> </div> --- class: inverse, middle, center ## *"perhaps the most important part of applied statistical modelling"* ### Simon Wood --- # Model checking - Checking `\(\neq\)` validation! - As with detection function, checking is important - Want to know the model conforms to assumptions - What assumptions should we check? --- # What to check - Convergence - Basis size - Residuals --- class: inverse, middle, center # Convergence --- # Convergence - Fitting the GAM involves an optimization - By default this is REstricted Maximum Likelihood (REML) score - Sometimes this can go wrong - R will warn you! --- # A model that converges ```r gam.check(dsm_tw_xy_depth) ``` ``` ## ## Method: REML Optimizer: outer newton ## full convergence after 7 iterations. ## Gradient range [-3.456333e-05,1.051004e-05] ## (score 374.7249 & scale 4.172176). ## Hessian positive definite, eigenvalue range [1.179219,301.267]. ## Model rank = 39 / 39 ## ## Basis dimension (k) checking results. Low p-value (k-index<1) may ## indicate that k is too low, especially if edf is close to k'. ## ## k' edf k-index p-value ## s(x,y) 29.00 11.11 0.65 <2e-16 *** ## s(Depth) 9.00 3.84 0.81 0.38 ## --- ## Signif. codes: 0 '***' 0.001 '**' 0.01 '*' 0.05 '.' 0.1 ' ' 1 ``` --- # A bad model ``` Error in while (mean(ldxx/(ldxx + ldss)) > 0.4) { : missing value where TRUE/FALSE needed In addition: Warning message: In sqrt(w) : NaNs produced Error in while (mean(ldxx/(ldxx + ldss)) > 0.4) { : missing value where TRUE/FALSE needed ``` This is **rare** --- class: inverse, middle, center # The Folk Theorem of Statistical Computing ## *"most statistical computational problems are due not to the algorithm being used but rather the model itself"* ### Andrew Gelman --- class: inverse, middle, center # Basis size --- # Basis size (k) - Set `k` per term - e.g. `s(x, k=10)` or `s(x, y, k=100)` - Penalty removes "extra" wigglyness - *up to a point!* - (But computation is slower with bigger `k`) --- # Checking basis size ```r gam.check(dsm_x_tw) ``` ``` ## ## Method: REML Optimizer: outer newton ## full convergence after 7 iterations. ## Gradient range [-3.196351e-06,4.485623e-07] ## (score 409.936 & scale 6.041307). ## Hessian positive definite, eigenvalue range [0.7645492,302.127]. ## Model rank = 10 / 10 ## ## Basis dimension (k) checking results. Low p-value (k-index<1) may ## indicate that k is too low, especially if edf is close to k'. ## ## k' edf k-index p-value ## s(x) 9.00 4.96 0.76 0.44 ``` --- # Increasing basis size ```r dsm_x_tw_k <- dsm(count~s(x, k=20), ddf.obj=df, segment.data=segs, observation.data=obs, family=tw()) gam.check(dsm_x_tw_k) ``` ``` ## ## Method: REML Optimizer: outer newton ## full convergence after 7 iterations. ## Gradient range [-2.301263e-08,3.930695e-09] ## (score 409.9245 & scale 6.033913). ## Hessian positive definite, eigenvalue range [0.7678456,302.0336]. ## Model rank = 20 / 20 ## ## Basis dimension (k) checking results. Low p-value (k-index<1) may ## indicate that k is too low, especially if edf is close to k'. ## ## k' edf k-index p-value ## s(x) 19.00 5.25 0.76 0.37 ``` --- # Sometimes basis size isn't the issue... - Generally, double `k` and see what happens - Didn't increase the EDF much here - Other things can cause low "`p-value`" and "`k-index`" - Increasing `k` can cause problems (nullspace) --- # k is a maximum - Don't worry about things being too wiggly - `k` gives the maximum complexity - Penalty deals with the rest ![](dsm3-model-checking_files/figure-html/plotk-1.png)<!-- --> --- class: inverse, middle, center # Residuals --- # What are residuals? - Generally residuals = observed value - fitted value - BUT hard to see patterns in these "raw" residuals - Need to standardise `\(\Rightarrow\)` **deviance residuals** - Residual sum of squares `\(\Rightarrow\)` linear model - deviance `\(\Rightarrow\)` GAM - Expect these residuals `\(\sim N(0,1)\)` --- # Residual checking ![](dsm3-model-checking_files/figure-html/gamcheck-1.png)<!-- --> --- # Shortcomings - `gam.check` can be helpful - "Resids vs. linear pred" is victim of artifacts - Need an alternative - "Randomised quanitle residuals" (*experimental*) - `rqgam.check` - Exactly normal residuals --- # Randomised quantile residuals ![](dsm3-model-checking_files/figure-html/rqgamcheck-1.png)<!-- --> --- # Residuals vs. covariates ![](dsm3-model-checking_files/figure-html/covar-resids-1.png)<!-- --> --- # Residuals vs. covariates (boxplots) ![](dsm3-model-checking_files/figure-html/covar-resids-boxplot-1.png)<!-- --> --- # Example of "bad" plots ![Bad residual check plot from Wood 2006](images/badgam.png) --- # Example of "bad" plots ![Bad residual check plot from Wood 2006](images/badgam-annotate.png) --- # Residual checks - Looking for patterns (not artifacts) - This can be tricky - Need to use a mixture of techniques - Cycle through checks, make changes recheck - Each dataset is different --- # Summary - Convergence - Rarely an issue - Check your thinking about the model - Basis size - k is a maximum - Double and see what happens - Residuals - Deviance and randomised quantile - check for artifacts - `gam.check` is your friend
